◆企業產品優點 Product features
1. 設計的創(chuang)意,形壯大方,環保型實際較好;
2. 可(ke)以(yi)調節式漩風(feng)溶合器,能(neng)將(jiang)可(ke)爐料與很小有害氣體溶合,好的(de)爐料不斷動用;
3. 其主(zhu)要零器(qi)件分為上(shang)等國外零配件,實用(yong)期限長;
4. 加工廠產品接觸面均;
5. 多工位器具設計制作;操作步驟方法員可同一時間操作步驟方法噴砂。要根據投資者具體需求,可以擇半自動的或自動的 ;可按業主需求訂制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆符合規模 Applicable scope
鋼(gang)板,筆記本護(hu)殼,揚(yang)聲器板材(cai),漢堡包(bao)烤盤等表面(mian)及方(fang)體零件(jian)的(de)噴砂加工處理(li)。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆重點工藝性能參數 Main technical parameters
|
機器(qi)人款型 Model |
STR-多工位輸送式噴砂機 |
|
服務器厚(hou)度 Complete machine size(mm) |
3000×1000×1700 |
|
業務辦公(gong)空間 Work space(mm) |
2000×1000×800 |
|
外運(yun)送規格 Conveying the size(mm) |
500×1000×1000(2件(jian)) |
|
降塵箱大小 Dedust box sizes(mm) |
600×600×1800 |
|
離心分(fen)離機無刷(shua)電機 Separator motor |
220V 50HZ 550W |
|
破乳器新風(feng)量 Separator air volume |
8.5m3/min |
|
擠(ji)壓大氣源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明 Floodlight |
兩盞30W防暴燈 |
|
服(fu)務器總重 Machine weight |
550kg |
